PECO Industrial Temperature Controller with Power Cord TF115P-002 Temperature Range 40°-110°F with Nema 4X Enclosure

Thermostat Peco RTU this fast, easy & portable temperature control at a specific location. TF115P-002 industrial application thermostat is built for long-term, reliable performance while withstanding harsh climate conditions. With simple plug-in set up, user just plugs it into device power source. Easy configuration for heating or cooling, makes portable use easy. Analog thermostat is has a rugged, weather resistant enclosure, which enables placement most anywhere. It tolerates moist conditions, performs despite water spray, high humidity, airborne contaminates & moderately corrosive conditions. Large, visible dial, makes set point temperatures clear. Enclosures comply with N.E.C. Article 547, giving code compliance peace-of-mind. Thermostat is built from corrosion resistant materials, allowing long life & reliable performance in most demanding climates.

Weights & Dimensions

• Physical Dimensions3.1" W X 7" H X 2.5" D
• Cord Length6 FT (1.83 m)
• Mounting Height About 5.9 to 11.8 (1.8 FT, 3.6M) FT
• Capillary Length Coiled Capillary FT
• Detectable Speed0.3, 10 FT/SEC (0.1, 3M/SEC)

Product Details

• Switch Action SPDT
• Temperature Control Range40 to 110 °F
• Power TypePlug In
• TypeMechanical
• For Use WithRefrigeration / Industrial / Agricultural
• Amps High13 A
• Differential Temperature3 °F
• Electrical Ratings13 AMP @120 VAC
• Low Temperature Limit59°/55°/51°F (15°/13°/11°C) °F
• BulbCoiled Air- Stainless
• Detection Range110°, 50'x50' (15x15M) At 77°F (25°C)
• Voltage120 V
• Relay OutputForm C, 24V/Dry Contact Selectable
• Relay ContactAC: 250V, Dc: 30V, 5A Resistive Load
• BrandPeco
• StagesSingle
• Max Ambient Temperature140
• Temperature Operating Range40 to 110 °F
• High Temperature Limit85°/82°/79°F (30°/28°/26°C)
• Manufacturers Part NumberTF115P-002
• Color Family Gray

This thermostat has a gas filled coil for great reliability. Give or take 2 degrees of accuracy. Turns fan ON when the temperature has reached 4 degrees above set point and turns fan OFF at 3 degrees below set point. Simply plug your fan into the thermostat’s cord, set the dial and you’re done. This thermostat is humidity resistant.

The Cruise Temp CT-EC cooling and heating thermostat has a gas filled coil for great reliability. It comes prewired for cooling, but can easily be switched to operate heating devices by switching one wire. Turns cooling fan ON when the temperature reaches 4 degrees above set point and turns OFF at 3 degrees below set point. The Cruise Temp features a combination plug and receptacle power cord design; simply plug your fan into the thermostat's cord, set the dial and you're done. Thermostat is humidity resistant. Accuracy is +/- 2 degrees.
